active::math Namespace Reference

Functions
bool	isLess (double val1, double val2, double prec=eps)
bool	isEqual (double val1, double val2, double prec=eps)
bool	isGreater (double val1, double val2, double prec=eps)
int	compare (double val1, double val2, double prec=eps)
bool	isLessOrEqual (double val1, double val2, double prec=eps)
bool	isGreaterOrEqual (double val1, double val2, double prec=eps)
bool	isLessZero (double val, double prec=eps)
bool	isLessOrEqualZero (double val, double prec=eps)
bool	isZero (double val, double prec=eps)
bool	isGreaterOrEqualZero (double val, double prec=eps)
bool	isGreaterZero (double val, double prec=eps)
bool	isBetween (double val, double lower, double upper, double prec=eps)
bool	isWithin (double val, double lower, double upper, double prec=eps)
double	fMod (double val1, double val2, double prec=eps)
template<class T >
const T &	minVal (const T &val1, const T &val2)
template<class T >
const T &	maxVal (const T &val1, const T &val2)
double	round (const double &val, double module=eps)
	Rounding functions.
double	roundUp (const double &val, double module=eps, double tolerance=eps)
double	roundDown (const double &val, double module=eps, double tolerance=eps)
double	sign (const double &val, double prec=eps)
template<class T >
T	sgn (const T &val)
template<class T >
T	flow_sgn (const T &val)
double	angleMod (double angle)
	Calculate an angle as a value between 0 to 2.pi radians.
bool	dividesInto (double val, double div, double prec=eps)
	Determine if an angle divides cleanly into another angle.
bool	isAngleBetween (double val, double lower, double upper, double prec=eps)
	Determine if an angle is bounded between two other angles.
bool	isAngleWithin (double val, double lower, double upper, double prec=eps)
	Determine if an angle is bounded within two other angles.
bool	isEqualAngle (double angle1, double angle2, double prec=eps)
	Determine if two angles are equal.
bool	isParallelAngle (double angle1, double angle2, double prec=eps)
	Determine if two angles are parallel.
bool	isPerpendicularAngle (double angle1, double angle2, double prec=eps)
	Determine if two angles are perpendicular.
double	angleDelta (double angle1, double angle2)
	Get a change in angle from 180 to -180.

Variables
constexpr double	pi = std::numbers::pi_v<double>
constexpr double	eps = 1e-5
	Default length precision (0.01mm)
constexpr double	epsAngle = pi / 1800
	Default angle precision (0.1 degrees)
constexpr double	radianToDegree = 180.0 / pi
	Angle unit conversions.
constexpr double	degreeToRadian = 1.0 / radianToDegree
constexpr double	radianToMinute = radianToDegree * 60
constexpr double	minuteToRadian = 1.0 / radianToMinute
constexpr double	radianToSecond = radianToMinute * 60
constexpr double	secondToRadian = 1.0 / radianToSecond
constexpr double	radianToGrad = radianToDegree * 10.0 / 9.0
constexpr double	gradToRadian = 1.0 / radianToGrad
constexpr double	inchToMillimetre = 25.4
	Length unit conversions.
constexpr double	pointToMillimetre = 0.3527777777778
constexpr double	footToInch = 12
constexpr double	yardToFoot = 3
constexpr double	metreToKilometre = 1000
constexpr double	metreToDecimetre = 10
constexpr double	metreToCentimetre = 1e2
constexpr double	metreToMillimetre = 1e3
constexpr double	metreToInch = metreToMillimetre / inchToMillimetre
constexpr double	metreToFoot = metreToInch / footToInch
constexpr double	metreToYard = metreToFoot / yardToFoot
constexpr double	metreToMile = 0.0006213712
constexpr double	metre2ToMillimetre2 = metreToMillimetre * metreToMillimetre
	Area unit conversions.
constexpr double	metre2ToCentimetre2 = metreToCentimetre * metreToCentimetre
constexpr double	metre2ToAre = 0.01
constexpr double	metre2ToHectare = 0.0001
constexpr double	metre2ToInch2 = metreToInch * metreToInch
constexpr double	metre2ToFoot2 = metreToFoot * metreToFoot
constexpr double	metre2ToYard2 = metreToYard * metreToYard
constexpr double	metre2ToMile2 = metreToMile * metreToMile
constexpr double	metre3ToLitre = 1000.0
	Volume unit conversions.
constexpr double	metre3ToCentimetre3 = metre2ToCentimetre2 * metreToMillimetre
constexpr double	metre3ToMillimetre3 = metre2ToMillimetre2 * metreToCentimetre
constexpr double	metre3ToInch3 = metre2ToInch2 * metreToInch
constexpr double	metre3ToFoot3 = metre2ToFoot2 * metreToFoot
constexpr double	metre3ToYard3 = metre2ToYard2 * metreToYard
constexpr double	metre3ToGallon = 264.172051
constexpr double	kilogramToMilligram = 1000000.0
	Mass unit conversions.
constexpr double	kilogramToGram = 1000.0
constexpr double	kilogramToTonne = 0.001
constexpr double	kilogramToOunce = 35.2739619
constexpr double	kilogramToPound = 2.204622622
constexpr double	kilogramToStone = 0.15747304
constexpr double	kilogramToTon = 0.001102311

Detailed Description

Copyright 2024 Ralph Wessel and Hugh Wessel Distributed under the MIT License (See accompanying file LICENSE.txt or copy at https://opensource.org/license/mit/)

A collection of commonly used maths contants and functions

Function Documentation

compare()

int active::math::compare ( double val1, double val2, double prec = eps )

inline

Compare two floating point values (with precision)

Parameters

val1	The first value
val2	The second value
prec	The comparison precision (tolerance)

Returns

-1 if the first value is less than the second, 0 if the values are equal, 1 if the first value is greater than the second

Here is the call graph for this function:

isEqual()

bool active::math::isEqual ( double val1, double val2, double prec = eps )

inline

Determine if two floating point values are identical (with precision)

Parameters

val1	The first value
val2	The second value
prec	The comparison precision (tolerance)

Returns

True if the two values are identical

Here is the caller graph for this function:

isGreater()

bool active::math::isGreater ( double val1, double val2, double prec = eps )

inline

Determine if one floating point value is greater than another (with precision)

Parameters

val1	The first value
val2	The second value
prec	The comparison precision (tolerance)

Returns

True if the first value is greater than the second

Here is the caller graph for this function:

isLess()

bool active::math::isLess ( double val1, double val2, double prec = eps )

inline

Determine if one floating point value is less than another (with precision)

Parameters

val1	The first value
val2	The second value
prec	The comparison precision (tolerance)

Returns

True if the first value is less than the second

Here is the caller graph for this function:
